A language is learned through its big ideas and lived in through its small ones. This post is about the small ones in X_eTaL: how a lambda takes its arguments, including a new way to say that it ignores one; how a function that prints says so in its name; how two numbers are compared; how to see what a line of right-to-left code really means; and how an example in a comment becomes a test. The newest came from a side question this week.

Resource Link
The decisions lang-choices.md: L1 to L8 (lambdas), E1 and E2 (laziness), TU3 and TU4 (patterns), T3 (equality)
The lints docs/lint.md: unused-binding, missing-bang, needless-bang
The tools the README: xetal fmt, xetal run --echo and --box, xetal doc --test
The series Array Languages: every post
Comments Discord

A lambda’s arguments

Two ways to write a lambda

A lambda either uses the shorthand arguments or names its parameters, never both in one lambda (L5). The shorthand is typed _l and _r and drawn ⍺ and ⍵; how many of them the body uses decides how many arguments the lambda takes:

ᵘf̲n ← { ⍵ × 2 }
ᵘf̲n 5

10

ᵘf̲n ← { ⍺ − ⍵ }
3 ᵘf̲n 5

-2

Named parameters are listed before an arrow, and are drawn as written: { x → x × 2 } and { x y → x − y } are the same two functions. They desugar to nested one-argument lambdas (L4), so a two-argument function is curried.

⍺ and ⍵

The shorthand arguments were first drawn as small subscript l and r. They lasted a day: in my terminal’s font a subscript l was unreadable, and on the second day they became APL’s alpha and omega, which every APL reader already knows as a dfn’s left and right argument.

One rule keeps the shorthand honest (L1): _r alone makes a one-argument lambda, and _l exists only beside _r. A left argument with no right one is not a function X_eTaL can call, so the lambda is refused, with the fix:

ᵘf̲n ← { ⍺ × 2 }

error[bad-lambda]: a lambda using _l must also use _r; otherwise name the parameters

Nothing: @

A function of no arguments takes @, the unit value, and is called with it (L6):

ᵘf̲n ← { @ → 42 }
ᵘf̲n @

42

It takes only @. Called with a number, it is a type error before the program runs, expected Unit, found a number. A lambda with no arguments at all, { 42 }, is refused: a lambda needs ⍵, ⍺ and ⍵, named parameters, or @ →.

Ignored: ▁

The newest case came from a side question. A function had to accept an argument and had no use for it:

ᵘn̲ope ← { na → 42 }

It runs, and xetal lint warns, correctly as far as it could tell, that the parameter is never used. Until this week the only way to say “unused on purpose” was a directive, # lint: allow unused-binding, at the end of the line or on the line before. That was a deliberate choice, made when the lint was (D140): no spelling of a name would opt out. It was wordy for a common case, and it said “the warning is wrong here” rather than “there is nothing here to use”.

So X_eTaL now has a third shorthand name, _u, for a parameter that is taken and dropped (L8, 7d811a0). It stands only in a parameter list, may repeat, and is never read: using it in the body is an error that says to name it. The linter never flags it, so no directive is needed, and the warning for an ordinary unused name now says what to write instead:

warning[unused-binding]: parameter `na` is never used; write `_u` for a parameter nothing reads at nope.xtl:1:14

It is drawn as a heavy low line, ▁, a thicker underscore, so that it reads as an empty slot:

ᵘf̲n ← { ▁ → 42 }
ᵘf̲n 5

42

Why not _, which already means “discard”? Because it already has its job: _ := expr keeps a value only for its effect, and (a, _) skips a part of a pair (TU4). Keeping _ to values and _u to parameters means each spelling has one meaning.

_u also fills the gap that L1 leaves. A two-argument function that ignores its right argument has no shorthand, since { ⍺ × 2 } is refused, but it has a short named form that says what it drops:

ᵘf̲n ← { x ▁ → x × 2 }
3 ᵘf̲n 5

6

That is the Kestrel, the bird that keeps its first argument, and X_eTaL’s own Combinators library now writes it this way:

ˡK̲ ← { x ▁ → x }

Lazy: ~

Arguments are evaluated before the function runs, right to left (E4), unless a parameter is marked lazy with ~: then its argument is evaluated where the body first reads it, and never if the body does not (E1). The Sage bird needs it, since a strict fixed point would recurse forever; here it makes the factorial out of a lambda that receives itself:

"c:" u̲se< "Combinators"
ᵘf̲n ← { ~s̲elf n → n ≤ 1 ? 1◆ n × s̲elf n − 1 }
'ᵘf̲n ᶜY̲ 5

120

Laziness also protects a function from an argument it does not need, and with ▁ the two combine. The tour’s ᵘk̲eep returns its left argument and drops its right. Dropped but not lazy, the caller’s 1 ÷ 0 is still computed first, and stops the program:

ᵘk̲eep ← { a ▁ → a }
7 ᵘk̲eep 1 ÷ 0

error[division-by-zero]: division by zero

Dropped and lazy, as the tour writes it, the argument is never computed at all:

ᵘk̲eep ← { a ~▁ → a }
7 ᵘk̲eep 1 ÷ 0

7

{ a ~▁ → a } says three things at once: the right argument is taken, it is dropped, and it is never even computed. Before _u, the tour wrote { a ~b → a } with a lint directive above it.

Patterns

A parameter can also be a tuple pattern, which takes a pair apart as it arrives (TU3), and _ skips a part:

ᵘf̲n ← { (a, b) → a + b }
ᵘf̲n (3, 4)

7

{ (a, _) → a } gives 3 for the same call.

Every shape

Shape Definition Call Result
no argument ᵘf̲n ← { @ → 42 } ᵘf̲n @ 42
one, used (shorthand) ᵘf̲n ← { ⍵ × 2 } ᵘf̲n 5 10
one, used (named) ᵘf̲n ← { x → x × 2 } ᵘf̲n 5 10
one, ignored ᵘf̲n ← { ▁ → 42 } ᵘf̲n 5 42
two, used (shorthand) ᵘf̲n ← { ⍺ − ⍵ } 3 ᵘf̲n 5 -2
two, used (named) ᵘf̲n ← { x y → x − y } 3 ᵘf̲n 5 -2
two, right ignored ᵘf̲n ← { x ▁ → x × 2 } 3 ᵘf̲n 5 6
two, left ignored ᵘf̲n ← { ▁ y → y × 2 } 3 ᵘf̲n 5 10
two, both ignored ᵘf̲n ← { ▁ ▁ → 0 } 3 ᵘf̲n 5 0
ignored, never computed ᵘf̲n ← { a ~▁ → a } 7 ᵘf̲n 1 ÷ 0 7
lazy, used ᵘf̲n ← { ~s̲elf n → n ≤ 1 ? 1◆ n × s̲elf n − 1 } 'ᵘf̲n ᶜY̲ 5 120
unit among named ᵘf̲n ← { @ x → x × 2 } @ ᵘf̲n 5 10
tuple pattern ᵘf̲n ← { (a, b) → a + b } ᵘf̲n (3, 4) 7
pattern part skipped ᵘf̲n ← { (a, _) → a } ᵘf̲n (3, 4) 3

And the spellings that are refused, each with the way out:

Definition Error
ᵘf̲n ← { ⍺ × 2 } bad-lambda: a lambda using _l must also use _r; otherwise name the parameters
ᵘf̲n ← { 42 } bad-lambda: a lambda needs _r, _l and _r, named parameters, or @ ->
ᵘf̲n ← { x → x + ⍵ } bad-lambda: do not mix named parameters with _l / _r
ᵘf̲n ← { ▁ + ⍵ } bad-lambda-arg: _u marks a parameter the lambda never uses ({ x _u -> x }); name it to use it, and write _r or _l in a shorthand lambda
ᵘf̲n ← { x ▁ → ▁ } bad-lambda-arg: the same

Effects are marked: !

A function that prints, reads, draws or changes something has a ! at the end of its name, p̲rint! and r̲oll! among the built-ins, so a reader can tell from a call alone whether it does anything besides return a value. The linter holds programs to it. A function that calls an effect without saying so:

ᵘs̲ay ← { x → p̲rint! x }
_ ← ᵘs̲ay "hello"

warning[missing-bang]: function `u:s_ay` calls `p_rint!`, an effect, but its name has no `!`: write `u:s_ay!` at bang.xtl:1:1

xetal lint --fix renames it, at its definition and at every use in the file, in one edit:

ᵘs̲ay! ← { x → p̲rint! x }
_ ← ᵘs̲ay! "hello"

The opposite slip, a ! on a function that does nothing but compute, is needless-bang. It is in the pedantic group, allowed by default, and reported with -W pedantic.

Exact, and tolerant beside it

= is exact (T3). It is IEEE equality and nothing else, so it is transitive, and it says what floating point does:

(0.1 + 0.2) = 0.3
(0.1 + 0.2) e̲q~ 0.3
0.1 + 0.2

0
1
0.30000000000000004

APL compares within a tolerance set by a system variable, and every comparison in a program depends on its current value. X_eTaL keeps the exact comparison as the default and puts the tolerant one beside it as a function of its own, e̲q~, with a fixed relative tolerance of about 1e-14. Which comparison is meant is written at the comparison, and nothing elsewhere can change it.

Seeing what a line means

Right-to-left reading with no precedence is simple to state and easy to misread at first. Three tools show what a line means. xetal fmt prints its canonical form, every application in parentheses:

'+ r̲/ 1 + 2 3 × 4
m ← 2 3 r̲eshape r̲ange 6
'+ r̲/₁ m

('+ r_/ (1 + (2 3 * 4)))
m := (2 3 r_eshape (r_ange 6))
('+ r_/_1 m)

The first line is 22: 2 3 × 4 is 8 12, plus 1 is 9 13, and the sum of those is 22. xetal run --echo runs a file as a notebook, each statement drawn and followed by what it printed, the way an APL session shows input indented above its output:

      m ← 2 3 r̲eshape r̲ange 6
      m
1 2 3
4 5 6
      '+ r̲/₁ m
5 7 9

And --box draws every array the way APL2’s DISPLAY does, with its shape on the frame: → along a row, ↓ down the rows, ~ for numbers:

┌→────┐
↓1 2 3│
│4 5 6│
└~────┘
┌→────┐
│5 7 9│
└~────┘

Examples that are tests

A ## comment above a definition documents it, and xetal doc builds a cross-referenced site from those comments, as rustdoc does for a crate. Inside one, >> marks an example and the lines after it are what it prints:

⍝│ m_ean v: the arithmetic mean of v.
⍝│ >> "a:" u_se< "Avg"
⍝│ >> a:m_ean 1 2 3 4
⍝│ 2.5
ˡm̲ean ← { v → ('+ r̲/ v) ÷ f̲loat t̲ally v }

xetal doc --test runs every example and compares:

doc tests in Avg.xtl: 2 examples
l:m_ean >> "a:" u_se< "Avg" ... ok
l:m_ean >> a:m_ean 1 2 3 4 ... ok
doc test result: ok. 2 passed; 0 failed

An example whose output no longer matches fails, with both versions shown, so documentation cannot drift from the code it describes:

---- l:m_ean >> a:m_ean 1 2 3 4
--- expected
2.4
--- actual
2.5
doc test result: FAILED. 1 passed; 1 failed
error[doc-test-failed]: 1 doc example(s) failed in bad/Avg.xtl

The standard libraries are documented this way: fifteen of the Combinators library’s birds carry an example, and each one is a doc test.
